China factory price gold mining equipment mineral gravity separator 6s shaking table

Machine Description:

Shaking table is one of the major gravity ore dressing machines, in some aspect it is the most important gravity ore dressing machine. It is designed to separate & recover those small even very fine size rare metal & precious material, especially for gold recovery from alluvial deposit / rock stones.

Theshaking table separate the mineral granular based on the gravity differences between the different material. When ore slurry reaches the table surface from the feeding box, the granular in it will be effected by the gravity force, water flow force, the inertial force and friction force which comes from the reciprocating movement of the table surface. Under the effect of these four forces, the granular inside the pulp will be classified and moved to different directions: the high density ore will go front and drop from the concentration end, the gangue will go to the tailings side, and the middling could be re-separated on the shaking table.

Technical Specification

Shaking Tables have three distinct deck designs available.

The course ore deck is designed for recovering particles sized from 0.5 mm to 2 mm; the fine sand deck is designed for recovering fine particles in the range of 0.074 mm to 0.5 mm; the slime deck is designed for recovering super extremely fine particles in the range of 0.05 mm to 0.074 mm.

Machine Construction:

Head Motion  The head motion is of rugged construction and requires minimum maintenance. Its internal mechanism is splash lubricated from an integral oil sump.

Decks   The decks are built of 16 mm zircon-reinforced fiberglass with fabricated steel frames at the bottom and are easy to clean, requiring little maintenance. The specific gravity of fiberglass made into decks is one third of that of steel, while its strength reaches as high as 70% that of steel. This fiberglass desks also has the characteristic of water-resistance and corrosion-resistance and can hold the shape unchangeable at ±50°C.

Feed and Water Box A wooden feed distributing box with hopper and a long water box are attached to the iron of the deck, giving a very even distribution of feed and water.

Base   A choice of ordinary type, groove steel support or big channel steel support is available.

Application:

Concentrating Tables are designed to wet gravity-based separation of minerals and other granular materials.

There are many applications where the concentrating table is of particular value and cannot be equaled for economical and efficient performance. They are effective in processing precious and base metal, rare metal and non-metallic minerals.

FAQ:

1. Q: Can I visit your factory?
A: Yes. Many domestic and overseas customers visited our factory every year.

2. Q: What about the warranty of your equipment? Do you supply spare parts?
A: Our warranty is one year(12 months), and we can supply spare parts also.

3. Q: Do you provide after-sales service?
A: Yes. We have a professional after-sale service team to promptly and thoroughly solve your problems.

4. Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passport.

5. Q: Do you provide producution flow chart?
A: Yes. Our experienced engineers are specialized in designing process flow for various ores beneficiation, including iron ore, tin ore, copper ore, gold ore, lead zinc ore, manganese ore, etc.

6. Q: Can you test our sample ore?
A: Yes. You can send your samples to us for testing and analysis.

7. Q: Have you made the whole ore dressing lines?
A: Yes. We have made many large&small scale ore dressing lines at home and abroad.

Company Information:

Jiangxi Hengcheng Mining Equipment Company is specialized in manufacturing various kinds of mining equipment. We have served the mineral processing industry as an excellent mineral processing equipment manufacturer for over 20 years.

Hengcheng company is dedicated to provide a complete line of equipment including shaking table, spiral chute, jig machine ,trommel,rotary scrubber, flotation machine, magnetic separator ,grinding mill, and so on. We are involved in the range of mineral beneficiation services including mineral testing, process flowchart design, installation and commissioning, technical consulting, as well as staff training, etc. Our proven technologies and experience permit us to provide every customer with the most efficient & commercial beneficiation plant equipment.

Warmly welcome you come to visist our factory.

Our factory located at Ganzhou city, Jiangxi province, China.

Take flight from your country to Guangzhou airport in China, and then take flight from Guangzhou-- to Gan zhou airport, then we will send the car to pick up you from Ganzhou airport.
